Laboratory Grade Casework & Cabinet Construction (SEFA 8 Compliant) UniLine Casework is constructed of welded 18 gauge steel. Powder coat finish is environment friendly, attractive and long lasting, color: Lab White. Modular design allows for simple field conversion from inlet to overlay, door and drawer re-configurations and hardware component changes. Casework is tested independently to be SEFA 8 load bearing capacity compliant. |
|
![Casework Casework](images/lab_furn images/CaseWorkConst4.jpg) |
Drawer Bodies constructed of 20 gauge steel. 18 gauge drawer suspension with full extension ball bearing drawer slide. File drawer suspension available in both 100 and 150 lb capacity. Exterior is urethane powder coated steel, for chemical and abrasion resistance.
Doors double wall construction with 20 gauge reinforcing channel (1) per door. Rubber door bumpers (4) per door. Five knuckle hinges (2) per door. Nylon roller catch (1) per door. Urethane powder coated steel. Manual, self closing.
Cabinet Interior Full length & width adjustable 20 gauge steel shelf for maximum storage. Zinc plated adjustable steel shelf clips. Powder coated finish for chemical resistance. 18 gauge full height removable access panel. Color: Lab White
Recessed Toe Space promotes laboratory cleanliness. Cabinet base lower corner reinforcing gusset with 0 to 2-1/2” zinc leveling bolts on (all four corners). Cabinet height adjustable from 35” to 37”. 12 gauge steel corner gusset (4) each cabinet. |
|
|
|
UniLine Casework Groupings |
|
Unitized design incorporates our most popular casework groupings to meet your laboratory needs. Welded steel with chemical resistant, epoxy powder coat finish, and 1” thick phenolic resin countertops, 4” high backsplashes, and flush ends standard. ADA height 34” Max, and sitting height 28”, options are available. Standard color: Lab White, unless otherwise specified. |
|
Atlantis Grouping
Atlantis Grouping provides basic lab storage & a versatile work area. Cabinet grouping includes 3 standing height cabinets with rear filler panels on both ends, phenolic resin worksurface with 4” high back splash. Includes 16” X 12” X 8” sink and H/C gooseneck faucet.
Atlantis Cabinet Grouping |
Width |
1 |
2 |
3 |
24” Depth Cat. No. |
30” Depth Cat. No. |
108" |
36” |
36” |
36” |
70011 |
70021 |
120" |
36” |
48” |
36” |
70012 |
70022 |
144" |
48” |
48” |
48” |
70013 |
70023 |
|
|
![Atlantis Grouping Atlantis Grouping](images/lab_furn images/Atlantis1.jpg)
Image shows optional sink Cat No. 42022 |
|
|
|
Enterprise Grouping
Enterprise Grouping provides a convenient balance of storage and work space. Cabinet grouping includes 3 standing height cabinets with rear filler panels, 2 wall cabinets, phenolic resin worksurface with 4” high back splash. Includes 16” X 12” X 8” sink, 30" X 30" pegboard and H/C gooseneck faucet.
Enterprise Cabinet Grouping |
Width |
1 |
2 |
3 |
24” Depth Cat. No. |
30” Depth Cat. No. |
108" |
36” |
36” |
36” |
70211 |
70221 |
120" |
36” |
48” |
36” |
70212 |
70222 |
144" |
48” |
48” |
48” |
70213 |
70223 |
|
|
![](images/lab_furn images/Enteprise2.jpg) |
|
|
Image shows optional sink Cat No. 42022 |
Endeavour Island Grouping
Endeavour Grouping is a flexible design that can serve as an island or peninsula layout. Cabinet grouping includes either 3 or 7 standing height cabinets with front and end filler panels, phenolic resin worksurface, and center island reagent shelf with pedestals and phenolic resin shelf. Includes 16” X 12” X 8” sink, 30" X 30" pegboard and H/C gooseneck faucet.
Endeavor Cabinet Grouping |
Width |
1 |
2 |
3 |
4 |
Cat. No. |
101” |
36” |
36” |
— |
60" |
71311 |
137” |
36” |
36” |
36” |
60" |
71312 |
173” |
48” |
48” |
48” |
60" |
71313 |
|
|
![Endeavour Island Grouping Endeavour Island Grouping](images/lab_furn images/Endeavor1.jpg) |
|
|
Image shows optional sink Cat No. 42022 |
|
|
|
Artemis Grouping
UniLine Artemis Grouping provides ample lab storage with options. Cabinet grouping includes (3) 36” high cabinets, phenolic resin worksurface with 4” high back splash. Includes 16” X 12” X 8” sink and H/C gooseneck faucet, and three wall cabinets. Add a UniFlow SL fume hood in widths of 48”, 60”, 72”, and 96” wide.
Artemis Cabinet Grouping |
Cat. No. |
Length |
1 |
2 |
Add a hood
Select 48”, 60”, 72”
or 96” SL
|
3 |
70901 |
108” |
36” |
36" |
36" |
70902 |
144” |
48” |
48” |
48” |
|
|
![](images/lab_furn images/Artemis2.jpg) |
|
|
|
Ranger Grouping
UniLine Ranger Grouping combines convenient basic lab storage. Grouping includes (3) 36” high cabinets with rear filler panels on both ends, phenolic resin worksurface with 4” high back splash. Add a UniFlow SL fume hood in widths of 48”, 60”, 72”, and 96” wide.
Ranger Cabinet Grouping |
Cat. No. |
Length |
1 |
Add a hood
Select 48”, 60”, 72”
or 96” SL
|
2 |
3 |
70911 |
108” |
36” |
36" |
36" |
70912 |
144” |
48” |
48” |
48” |
|
|
![Ranger Grouping Ranger Grouping](images/lab_furn images/Ranger1.jpg) |
|
|
|
Surveyor Grouping
UniLine Surveyor Grouping accommodates greater storage requirements. Grouping includes (3) cabinets 36” high, phenolic resin worksurface with 4” high backsplash, 16” X 12” X 8” sink, H/C gooseneck faucet and pegboard. Add a UniFlow SL fume hood in widths of 48”, 60”, 72”, and 96” wide.
Surveyor Cabinet Grouping |
Cat. No. |
Length |
1 |
2 |
3 |
Add a hood
Select 48”, 60”, 72”
or 96” SL |
70921 |
108” |
36” |
36" |
36" |
70922 |
144” |
48” |
48” |
48” |
|
|
![Surveyor Grouping Surveyor Grouping](images/lab_furn images/Surveyor1.jpg) |
|
|
|
Lunar Grouping
UniLine Lunar Grouping provides lab storage. Cabinet grouping includes (3) 36” high cabinets with rear filler panels on the ends, and one floor storage cabinet, phenolic resin worksurface with 4” high back splash. Includes two wall cabinets. Add a UniFlow SL fume hood in widths of 48”, 60”, 72”, and 96” wide.
Lunar Cabinet Grouping |
Cat. No. |
Length |
Add a hood
Select 48”, 60”, 72”
or 96” SL |
1 |
2 |
3 |
70931 |
108” |
36" |
36" |
36" |
70932 |
144” |
48” |
48” |
48” |
|
|
![](images/lab_furn images/Lunar2.jpg) |
|
|
|
Viking / Magellan Grouping
Viking Grouping is ideal for medical examination rooms and small lab requirements. Cabinet grouping includes 1 or 2 standing height cabinets, 1 wall cabinet 36" or 48" wide, 24" high 12" deep, phenolic resin worksurface. Includes 16” X 12” X 8” sink and H/C gooseneck faucet.
Viking Cabinet Grouping |
Width |
1 |
2 |
24” Depth Cat. No. |
30” Depth Cat. No. |
72" |
36” |
36” |
70413 |
70423 |
96" |
48” |
48” |
70414 |
70424 |
Magellan Cabinet Grouping |
Width |
1 |
24” Depth Cat. No. |
30” Depth Cat. No. |
36" |
36" |
70611 |
70621 |
48" |
48" |
70612 |
70622 |
|
|
![](images/lab_furn images/Viking2.jpg) |
|
|
|
Gemini Grouping
UniLine Gemini grouping features a sitting height desk area that can be incorporated with any of the HEMCO groupings. Cabinet grouping includes 1 sitting height file drawer cabinet with rear filler panels, single drawer apron, and phenolic resin worksurface. Sitting height 28”.
Gemini Cabinet Grouping |
Length |
1 |
2 |
24” Depth Cat. No. |
30” Depth Cat. No. |
48” |
30" |
18" |
70501 |
70521 |
54" |
36” |
18” |
70502 |
70522 |
66" |
48” |
18” |
70503 |
70523 |
|
|
![Gemini Grouping Gemini Grouping](images/lab_furn images/Gemini4.jpg) |
|
|
|
UniLine Base Cabinets (standard color: White, unless otherwise specified) |
|
Lab cabinets are offered in standard modular sizes that allow you to create a custom laboratory to meet your specific needs. All cabinets feature furniture grade welded steel construction with a durable, chemical resistant, epoxy powder coat finish that meet or exceed SEFA 8, recommended practice for laboratory casework. Other colors available to suit your requirements. (Available in Stainless Steel and Polypro)(and ADA heights) |
|
![Cabinet End View Cabinet End View](images/lab_furn images/Base1C.jpg) |
![3 Drawer 3 Drawer](images/lab_furn images/Base2D.jpg) |
![4 Drawer 4 Drawer](images/lab_furn images/Base3C.jpg) |
![1 Drawer - 1 Door 1 Drawer - 1 Door](images/lab_furn images/Base4C.jpg) |
![1 Door 1 Door](images/lab_furn images/Base5C.jpg) |
3 Drawer |
4 Drawer |
1 Drawer - 1 Door |
1 Door |
Cabinet End View |
Width |
Cat. No. |
18” |
70701 |
24” |
70702 |
|
Width |
Cat. No. |
18” |
71221 |
24” |
71222 |
|
Width |
Cat. No. |
18” |
71181 |
24” |
71182 |
Specify left or right hinged |
|
Width |
Cat. No. |
18” |
71951 |
24” |
71952
|
Specify left or right hinged |
|
|
|
![2 Drawer - 2 Door 2 Drawer - 2 Door](images/lab_furn images/Base6C.jpg) |
![1 Drawer - 2 Door 1 Drawer - 2 Door](images/lab_furn images/Base7C.jpg) |
![5 Drawer - 1 Door 5 Drawer - 1 Door](images/lab_furn images/Base8C.jpg) |
![4 Drawer - 1 Door 4 Drawer - 1 Door](images/lab_furn images/Base9C.jpg) |
![4 Drawer - 2 Door 4 Drawer - 2 Door](images/lab_furn images/Base10C.jpg) |
2 Drawer - 2 Door |
1 Drawer - 2 Door |
5 Drawer - 1 Door |
4 Drawer - 1 Door |
4 Drawer - 2 Door |
Width |
Cat. No. |
30” |
71061 |
36” |
71062 |
48” |
71064 |
|
Width |
Cat. No. |
30” |
71051 |
36” |
71052 |
48” |
71054 |
|
Width |
Cat. No. |
30” |
71131 |
36” |
71132 |
48” |
71134 |
|
Width |
Cat. No. |
30” |
71101 |
36” |
71102 |
48” |
71104 |
|
Width |
Cat. No. |
30” |
71081 |
36” |
71082 |
48” |
71084 |
|
|
![5 Drawer 5 Drawer](images/lab_furn images/Base11C.jpg) |
![8 Drawer 8 Drawer](images/lab_furn images/Base12C.jpg) |
![6 Drawer 6 Drawer](images/lab_furn images/Base13C.jpg) |
![4 Drawer 4 Drawer](images/lab_furn images/Base14C.jpg) |
![Vacuum Cabinet Vacuum Cabinet](images/lab_furn images/Base15C.jpg) |
5 Drawer |
8 Drawer |
6 Drawer |
4 Drawer |
Vacuum Cabinet |
Width |
Cat. No. |
30” |
71231 |
36” |
71232 |
48” |
71234 |
|
Width |
Cat. No. |
30” |
71241 |
36” |
71242 |
48” |
71244 |
|
Width |
Cat. No. |
30” |
71381 |
36” |
71382 |
48” |
71384 |
|
Width |
Cat. No. |
30” |
71211 |
36” |
71212 |
48” |
71214 |
|
Width |
Cat. No. |
30” |
71821 |
36” |
71822 |
48” |
71824 |
|
|
Fume Hood Base Cabinets & Tables |
|
Fume Hood
Base Cabinet |
Acid Cabinet |
Flammable Cabinet |
Sink Unit Cabinet |
Sink End Unit |
![Fume Hood Base Cabinet Fume Hood Base Cabinet](images/lab_furn images/Base16C.jpg) |
![Acid Cabinet Acid Cabinet](images/lab_furn images/Base17C.jpg) |
![Flammable Cabinet Flammable Cabinet](images/lab_furn images/Base18C.jpg) |
![Sink Unit Cabinet Sink Unit Cabinet](images/lab_furn images/Base19C.jpg) |
![Sink End Unit Sink End Unit](images/lab_furn images/Base20C.jpg) |
Constructed of furniture grade steel. With adjustable shelf and levelers. Standard depth is 22",
standard height is 36".
Standard color: white |
Interior is lined with one piece acid resistant white composite resin liner and all coved corners, for superior corrosion resistance, with vents and fixed shelf. Standard depth is 22", standard height is 36". |
Provides safe storage of flammables. Color: silver beige. Constructed of welded double wall furniture grade steel. Cabinet has an adjustable shelf and locking hinged doors. Meets NFPA codes. Standard depth is 22", standard height is 36". |
Constructed of furniture grade steel. Cabinet has hinged doors and levelers. Standard depth is 22", standard height is 36". |
Constructed of furniture grade steel. Cabinet has hinged doors and levelers. Standard depth is 22", standard height is 36".
Standard color: white |
Width |
Doors |
Cat. No. |
12" |
1 |
15120 |
18" |
1 |
15180 |
24" |
1 |
15240 |
30” |
2 |
15300 |
36” |
2 |
15360 |
42" |
2 |
15420 |
48” |
2 |
15480 |
Vent Kit |
---- |
81000 |
|
Width |
Doors |
Cat. No. |
24" |
1 |
52411 |
30” |
2 |
53011 |
36” |
2 |
53611 |
48” |
2 |
54811 |
60" |
2 |
56011 |
|
Width |
Doors |
Cat. No. |
24" |
1 |
18020 |
30” |
2 |
18300 |
36” |
2 |
18030 |
48” |
2 |
18040 |
Vent Kit |
---- |
81000 |
|
Width |
Doors |
Cat. No. |
24" |
1 |
71810 |
30” |
2 |
71811 |
36” |
2 |
71812 |
48” |
2 |
71814 |
60" |
2 |
71815 |
|
Width |
Cat.No. |
52” |
71881 |
58” |
71882 |
|
|
UniLine Wall Cabinets, Floor Cabinets |
Wall Cabinets |
![Single Door Wall Cabinet Single Door Wall Cabinet](images/lab_furn images/Cab1A.jpg) |
![2 Door Wall Cabinet 2 Door Wall Cabinet](images/lab_furn images/Cab2B.jpg) |
![2 Door Framed Glass Cabinet 2 Door Framed Glass Cabinet](images/lab_furn images/Cab3A.jpg) |
![2 Glass Sliding Door Cabinet 2 Glass Sliding Door Cabinet](images/lab_furn images/Cab4A.jpg) |
Single Door Wall Cabinet |
2 Door Wall Cabinet |
2 Door Framed Glass Cabinet |
2 Glass Sliding Door Cabinet |
Width |
Height |
Depth |
Cat. No. |
18” |
30” |
12” |
72171 |
24” |
30” |
12” |
72172 |
Specify left or right hinged |
|
Width |
Height |
Depth |
Cat. No. |
30” |
30” |
12” |
72031 |
36” |
30” |
12” |
72032 |
48” |
30” |
12” |
72034 |
|
Width |
Height |
Depth |
Cat. No. |
30” |
30” |
12” |
72061 |
36” |
30” |
12” |
72062 |
48” |
30” |
12” |
72064 |
|
Width |
Height |
Depth |
Cat. No. |
30” |
30” |
12” |
72191 |
36” |
30” |
12” |
72192 |
48” |
30” |
12” |
72194 |
|
|
Floor Mounted Cabinets (Standard color: Lab White) |
|
![Floor Cabinet Floor Cabinet](images/lab_furn images/Cab5A.jpg) |
Floor Cabinet
Open Front
Storage cabinet with 5 adjustable shelves.
Height 84”, Depth 18” |
![Floor Cabinet Floor Cabinet](images/lab_furn images/Cab6A.jpg) |
Floor Cabinet
Solid Hinge Door
Storage cabinet with 5 adjustable shelves.
Height 84”, Depth 18” |
![Floor Cabinet Floor Cabinet](images/lab_furn images/Cab7A.jpg) |
Floor Cabinet
Slide Glass Door
Storage cabinet has glazed 1/4” glass doors and 5 adjustable shelves.
Height 84”, Depth 18” |
Width |
Cat. No. |
30” |
73381 |
36” |
73382 |
48” |
73384 |
|
Width |
Cat. No. |
30” |
73321 |
36” |
73322 |
48” |
73324 |
|
Width |
Cat. No. |
30” |
73371 |
36” |
73372 |
48” |
73374 |
|
|
Casework Accessories (Standard color: Lab White) |
|
![Reagent Shelf Reagent Shelf](images/lab_furn images/Cab8C.jpg) |
![Single Drawer Apron Single Drawer Apron](images/lab_furn images/Cab9C.jpg) |
![Wall Shelf Wall Shelf](images/lab_furn images/Cab10C.jpg) |
![Knee Space Panel Knee Space Panel](images/lab_furn images/Cab11C.jpg) |
Reagent Shelf
Shelves 4” wide 12” deep & 16” high. For use on island, peninsula, or against wall. Phenolic Resin shelf is 1” thick & 14” deep |
Single Drawer Apron
4 1/2” high. Used to span knee
space area and support countertop. |
Wall Shelf
12” deep. Includes vertical flanges for mounting. |
Knee Space Panel
35” high. Located at the
rear of knee space areas. |
Length |
Cat. No. |
6’ |
75111 |
9’ |
75112 |
12’ |
75113 |
|
Width |
Depth |
Cat. No. |
30” |
22” |
74031 |
36” |
22” |
74032 |
48” |
22” |
74034 |
|
Width |
Cat. No. |
24” |
75911 |
30” |
75912 |
36” |
75913 |
48” |
75914 |
|
Width |
Cat. No. |
24” to 36” |
73261 |
36” to 48” |
73262 |
54” to 66” |
73263 |
|
|
![End Panel End Panel](images/lab_furn images/Cab12C.jpg) |
End Panel
35” high x 22” or 28” deep.
Used to support countertops
at the end or middle of a
knee space area.
Specify depth.
Cat. No. 73255 |
![Leg Assembly Leg Assembly](images/lab_furn images/Cab13C.jpg) |
Leg Assembly
35” high x 22” or 28” deep. Used to support countertops at the end or middle of a knee space area. Please specify depth.
Cat. No. 73355 |
|
|
|
|
|
![Cabinet Lock Cabinet Lock](images/lab_furn images/Cab15C.jpg) |
Cabinet Lock
Five-Disc tumbler door & drawer cam lock & (2) keys
Cat. No. 75001 |
![Utility Chase Utility Chase](images/lab_furn images/Cab16C.jpg) |
Utility Chase
24” wide x 6” deep x 84” high. Located on an island behind a sink. Used to conceal piping and to serve as mounting for pegboard.
Cat. No. 75091 |
![Front Rail Front Rail](images/lab_furn images/Cab14C.jpg) |
Front Rail
2” high x 30”, 36” or 48” wide. Used to support counter tops above knee space areas. Please specify width.
Cat. No. 74015 |
|
![Rear Filler Panel Rear Filler Panel](images/lab_furn images/Cab17C.jpg) |
Rear Filler Panel
35” high x 7” wide. Used to enclose pipe chase behind cabinets on standard 30” deep counters.
Cat. No. 74112 |
![Center Filler Panel Center Filler Panel](images/lab_furn images/Cab18C.jpg) |
Center Filler Panel
35” high x 4”, 10”, or 14” wide. Used to enclose the pipe chase at the end of an island. Please specify width.
Cat. No. 74122 |
![Front Filler Panel Front Filler Panel](images/lab_furn images/Cab19C.jpg) |
Front Filler Panel
35” high x 2”, 6”, or 12” wide. Used to enclose the space between cabinets to meet casework length requirement. Please specify width.
Cat. No. 74142 |
![End Scribe End Scribe](images/lab_furn images/Cab20C.jpg) |
End Scribe
35” high x 2”, 6”, or 12” wide. Used to fill the space between the end of casework and a wall. Please specify width.
Cat. No. 74001 |
|
|
UniLine Acid Storage Cabinets |
|
For storage of ACID and corrosive chemicals, available in 12”, 18”, 24”, 30”, 36”, 42” & 48” widths. Standard 35” high and 22” deep cabinet dimension. (as shown) U.L. 1805 fume hoods & cabinets. |
|
![Acid Storage Cabinets Acid Storage Cabinets](images/lab_furn images/AcidCab1.jpg) |
|
Molded one piece chemical and acid resistant, composite liner, molded one-piece coved corners,glass smooth for ease of cleaning |
|
Cabinet Exhaust can be vented out the back or through the fume hood or through an exhaust blower system |
|
Removable rear panel allows access to connect venting |
|
Removable shelf for small container storage. |
|
Front Access doors are lined and edges are sealed |
|
Door Vents provide Supply airventilation |
|
Removable containment tray |
|
Containment Lip on front bottom edge of cabinet to hold spills |
For storage of ACID and corrosive chemicals, available in 12”, 18”, 24”, 30”, 36”, 42” & 48” widths. Standard 35 1/4” high and 22” deep cabinet dimension. (as shown) U.L. 1805 Fume Hoods & Cabinets. Cabinets are designed to hold specific chemicals |
![Containment Tray Containment Tray](images/lab_furn images/ContainmentTray.jpg)
|
Acid Storage Containment Tray to contain large spills and
provides ease of cleanup. (located in bottom of cabinet) |
![](images/lab_furn images/AcidCabs2.jpg)
|
Acid Cabinet Size |
Width |
12” |
18” |
24” |
30” |
36” |
42” |
48” |
35 1/4" high X 22" deep |
15120 |
15180 |
15240 |
15300 |
15360 |
15420 |
15480 |
|
![](images/lab_furn images/AcidCabDiagram.jpg) |
|
![](images/lab_furn images/AcidCab2022.jpg) |
Liquid Chemical Storage Cabinets shall be in an area of the laboratory with low traffic away from the main work area. It is important to segregate incompatible chemicals. Eliminate ignition sources such as open flame, hot surfaces, electrical equipment or static electricity from the storage area. Make sure appropriate fire extinguishers and/or sprinkler systems are in the area. An eyewash and safety shower must be readily accessible to areas where liquid chemicals are stored, per OSHA 1910.106(d)(3)(I).
Note: Venting voids the U.L. listing, If applicable, as site conditions cannot be verified by U.L. |
|
|
UniLine Flammable Storage Cabinets |
|
![Flammable Storage Cabinets Flammable Storage Cabinets](images/lab_furn images/FlammableCab.jpg) |
|
Doors One-piece double wall construction painted before assembly. Insulated door filler for added rigidity
and quiet operation. Rubber door bumpers. Powder coated finish. |
|
Cabinet Exhaust can be vented out the back or through the fume hood or through a exhaust blower system |
|
Removable Shelf for small container storage |
|
Cabinet interior bottom with a radius flange for increased strength and ease of cleaning. |
|
Containment Lip on front bottom edge of cabinet to hold spills |
|
Mobile Cabinets are available |
|
For storage of Flammable chemicals, available in 18”, 24”, 30”, 36” & 48” widths. Standard 35 1/4” high and 22” deep cabinet dimension. (as shown) U.L. 1805 Fume Hoods & Cabinets |
• Solvent Storage Cabinets are specifically designed for the
storage of flammable and combustible liquids.
• Construction meets the requirements listed by UFC, OSHA and NFPA No. 30-1993 and are UL listed.
• A 2” deep liquid-tight pan covers the entire bottom of the cabinet to contain liquid leaks and spills.
• Two diametrically opposed vents with spark screens are provided in the back of the cabinet as well as a grounding screw.
• Cabinets are labeled: FLAMMABLE - KEEP FIRE AWAY
• The right hand door is equipped with a three-point latching system. |
![Flammable Storage Cabinets Flammable Storage Cabinets](images/lab_furn images/FlammableCab2.jpg)
|
Flammable Cabinet Size |
Width |
18” |
24” |
30” |
36” |
48” |
35 1/4" high X 22" deep |
18010 |
18020 |
18300 |
18030 |
18040 |
|
![](images/lab_furn images/FlammableCab3.jpg) |
|
![Fire Extinguisher Fire Extinguisher](images/lab_furn images/FireExt1.jpg) |
|
Laboratory Countertops, Worksurfaces, Sinks |
|
Countertops are available in phenolic resin, epoxy resin, and stainless steel, are 24 or 30 inches deep, and can be supplied with or without back splashes. Sink and service cut-outs are fabricated as required. |
|
Laboratory Countertops |
![Phenolic Resin Phenolic Resin](images/lab_furn images/PhenolicWS.jpg) |
1. Phenolic Resin Surfaces are constructed of
solid composite panels that have excellent chemical resistance and durability. Surfaces are nonporous
and UV, heat, bacteria, and scratch resistant.
Available in 1" thickness.
Color: Charcoal (sold by the lineal foot) SEFA Compliant, UL1805 Certified. |
Depth |
24" Deep |
30" Deep |
No Backsplash |
Cat. No. 70118 |
Cat. No. 70018 |
With 4" Backsplash
|
Cat. No. 70118B |
Cat. No. 70018B |
|
|
![Epoxy Resin Epoxy Resin](images/lab_furn images/Worksurfaces_2.jpg) |
2. Epoxy Resin Surfaces & curbs are molded of a modified epoxy resin that is specifically compounded & cured to provide optimum physical & chemical resistance. Surfaces are nonporous, non-conductive, stain & heat resistant. Available in 1" thickness. Color: Black. (sold by the lineal foot) SEFA Compliant, UL1805 Certified. |
Depth |
24" Deep |
30" Deep |
No Backsplash |
Cat. No. 70115 |
Cat. No. 70015 |
With 4" Backsplash
|
Cat. No. 70115B |
Cat. No. 70015B |
|
|
![Stainless Steel Stainless Steel](images/lab_furn images/Worksurfaces_3.jpg) |
3. Stainless Steel Surfaces are fabricated of type 304,16 gauge steel with #3 satin finish. All corners, ends, and joints are continuous Heliarc welded and ground smooth. (type 316 stainless steel available)(sold by the lineal foot) |
Depth |
24" Deep |
30" Deep |
No Backsplash |
Cat. No. 70116 |
Cat. No. 70016 |
With 4" Backsplash
|
Cat. No. 70116B |
Cat. No. 70016B |
|
|
Laboratory Sinks & Plumbing |
|
A complete line of sinks in epoxy resin, polypropylene, and stainless steel. We also offer a wide variety of plumbing accessories including neutralization tanks and peg boards. HEMCO welcomes the opportunity to quote your special applications. Additional sink sizes are available. Conforms to ANSI Z21.15. available. |
|
(UniFlow SE, LE hoods only) Epoxy Resin, color: black, 1-1/4” thick, 3/8” dished |
|
![Epoxy Resin Worksurfaces Epoxy Resin Worksurfaces](images/work_surf images/WS7.jpg) |
Epoxy Resin Worksurfaces are recommended for general laboratory work where greater chemical resistance is required. Surface is dished 3/8" to contain spillage. Worksurface is cast of thermosetting epoxy resin, creating a molded solid 1-1/4" thick top which is extremely hard, abrasion and heat resistant. Tested to UL 1805 classification. |
Size |
Cat. No. |
Size |
Cat. No. |
36”W x 30”D |
20315 |
36”W x 36”D |
20325 |
48”W x 30”D |
20415 |
48”W x 36”D |
20425 |
60”W x 30”D |
20515 |
60”W x 36”D |
20525 |
72”W x 30”D |
20615 |
72”W x 36”D |
20625 |
96”W x 30”D |
20815 |
96”W x 36”D |
20825 |
|
(UniFlow SE, LE hoods only) Phenolic Resin, color: black, 1-1/4" thick |
|
![Phenolic Resin Worksurface Phenolic Resin Worksurface](images/work_surf images/WS8.jpg) |
Phenolic Resin Worksurfaces are recommended for general laboratory work where high concentrations of solvent, acids and alkalies are being worked with. Work surface combines excellent chemical resistance scratch and wear resistance. Surface is flat 1-1/4" thick.Tested to UL 1805 classification. |
Size |
Cat. No. |
Size |
Cat. No. |
36"W x 30"D |
21428 |
36"W x 36"D |
22428 |
48"W x 30"D |
21418 |
48"W x 36"D |
22418 |
60"W x 30"D |
21518 |
60"W x 36"D |
22518 |
72"W x 30"D |
21618 |
72"W x 36"D |
22618 |
96"W x 30"D |
21818 |
96"W x 36"D |
22818 |
|
(UniFlow SE, LE hoods only) Stainless Steel, satin finish, 1-1/4” edge, 3/8” dished |
|
![Stainless Steel Fume Hood Worksurfaces Stainless Steel Fume Hood Worksurfaces](images/work_surf images/WS9.jpg) |
Stainless Steel Fume Hood Worksurfaces are fabricated of type 304,16 gauge steel with #3 satin finish. Surface is dished 3/8” to contain spillage. All corners, ends, and joints are continuous 1-1/4” heliarc welded and ground smooth.
Type 316 stainless steel is also available. |
Size |
Cat. No. |
Size |
Cat. No. |
36”W x 30”D |
20316 |
36”W x 36”D |
20326 |
48”W x 30”D |
20416 |
48”W x 36”D |
20426 |
60”W x 30”D |
20516 |
60”W x 36”D |
20526 |
72”W x 30”D |
20616 |
72”W x 36”D |
20626 |
96”W x 30”D |
20816 |
96”W x 36”D |
20826 |
|
Laboratory Sinks & Plumbing |
|
A complete line of sinks in epoxy resin, polypropylene, and stainless steel. We also offer a wide variety of plumbing accessories includingneutralization tanks and steam baths. HEMCO welcomes the opportunity to quote your special applications. Additional sink sizes are available. Contact factory for more details. Conforms to ANSI Z21.15. |
|
Fume Hood Laboratory Sinks |
|
![Epoxy Resin Sink Epoxy Resin Sink](images/lab_furn images/Sink1.jpg) |
![Polypropylene sink Polypropylene sink](images/lab_furn images/Sink2.jpg) |
![Stainless Steel Sink Stainless Steel Sink](images/sp images/Stainless Steel Sink.jpg) |
Epoxy Resin Sink Laboratory sink made
of chemical and corrosion resistant epoxy resin. Drop-in sink. color: black. Please specify desired location. Includes sink stopper & drain outlet. |
Polypropylene Sink Laboratory sink made of chemical and corrosion resistant epoxy resin. Drop-in sink. color: black. Please specify desired location. Includes sink stopper & drain outlet. |
Stainless Steel Sink Laboratory sink made of one-piece, type 304 stainless steel & polished
to a No. 4 satin finish. Drop-in sink. Underside sound deadened to reduce drumming. Includes drain outlet. |
|
Size |
Cat. No. |
1 |
9” x 6” x 6” deep |
42021 |
2 |
16” x 12” x 8” deep |
42022 |
3 |
18” x 15” x 11” deep |
42026 |
4 |
24” x 16” x 8” deep |
42027 |
|
|
Size |
Cat. No. |
1 |
12” x 8” x 8” deep |
72041 |
2 |
14” x 10” x 6” deep |
72043 |
3 |
18” x 15” x 12” deep |
72045 |
4 |
28” x 20” x 9” deep |
72048 |
|
|
Size |
Cat. No. |
1 |
12” x 12” x 7.5” deep |
42031 |
2 |
16” x 16” x 7.5” deep |
42032 |
3 |
16” x 22” x 7.5” deep |
42033 |
4 |
16” x 28” x 7.5” deep |
42034 |
|
|
|
![Cupsink 6” Diameter Cupsink 6” Diameter](images/lab_furn images/Sink4.jpg) |
|
![Oval Cupsink Oval Cupsink](images/lab_furn images/Sink5.jpg) |
|
![Oval Wall Cupsink Oval Wall Cupsink](images/lab_furn images/Sink6.jpg) |
|
![Round Cupsink Round Cupsink](images/lab_furn images/Sink7.jpg) |
Cupsink 6” Diameter
Polypropylene cupsink with 1-1/2” IPS tailpiece and outlet strainer.
Cat. No. 40118 |
|
Oval Cupsink
Drop-in oval cupsink in polypropylene. 1-1/2” IPS tailpiece includes strainer.
3” x 6” |
40119 |
3” x 9” |
40121 |
|
|
Oval Wall Cupsink 6” x 3”
Cupsink is made of polypropylene
with 1-1/2” IPS tailpiece and outlet strainer. Optional on FM fume hoods Cat. No. 40419 |
|
Round Cupsink 9” Diameter
Cupsink is made of epoxy with 1-1/2” IPS tailpiece and outlet strainer.
Cat. No. 40519 |
|
Pegboard, P-Traps & Fume Hood Neutralization Tanks |
|
![Jar P-Trap Jar P-Trap](images/lab_furn images/PTrap.jpg) |
![P-Trap P Trap](images/lab_furn images/PTrap2.jpg) |
Jar P-Trap
P-trap includes adjustable tailpiece and removable jar.
1-1/2” IPS tail piece.
Cat. No. 40220 |
P-Trap
P-trap is made of polypropylene
with 1-1/2” IPS tailpiece.
Cat. No. 40120 |
![Pegboard Pegboard](images/lab_furn images/Pegboard1.jpg) |
Phenolic Resin Pegboards
For drying and storage of lab ware. Pegboard in 1” thick and includes a stainless steel drip trough to collect run-off. |
Width |
Height |
No. of Pegs |
Cat. No. |
24” |
30” |
39 |
72430 |
30” |
30” |
46 |
73030 |
30” |
36” |
60 |
73036 |
|
|
Neutralization Tanks Molded of one-piece,chemical resistant polyolefin, neutralization tanks are designed to dilute and neutralize laboratory waste and concentrated corrosives. Limestone is utilized as the medium for neutralizing the hazardous waste.
Note: limestone is not included with tank. |
![Neutralization Tank Neutralization Tank](images/lab_furn images/Tank1.jpg) |
![Neutralization Tank Neutralization tank](images/lab_furn images/Tank2.jpg) |
![Limestone Limestone](images/lab_furn images/Limestone.jpg) |
|
Description |
Cat. No. |
1 |
5 gallon tank (5.5” wide x 14” deep x 20” high with 1-1/2” IPS inlet/outlet) Note: 5 gallon tank requires (1) bag of limestone. |
40222 |
2 |
15 gallon tank (17.25” dia. x 15.5” H with 1-1/2” IPS inlet/outlet) Note: 15 gallon tank requires (3) bags of limestone. |
40322 |
3 |
Limestone is utilized as the medium for neutralizing the hazardous waste. (50 lb bag) Note: Limestone is not included with tank. |
40223 |
|
|
|
|
6 Liter |
8.5” H X 15.9” W X 12.3” deep |
Cat. No.
43020 |
20 Liter |
8.5” H X 15.9”W X 23.25” deep |
Cat. No.
43120 |
|
Laboratory Bead Baths
Easily change the temperature of the bath, without the wait times associated with water baths. Consistent temperatures & thermal uniformity of +/- 1.0 at 37 degrees Celsius. Bead Baths use beads instead of water, so you do not have to turn them off, and there is nothing to evaporate. |
![Bead Bath Bead Bath](images/lab_furn images/BeadBath.jpg) |
|
Laboratory Sinks & Plumbing |
|
The countertop service fixtures are chrome-plated. All fixtures have serrated hose connections except where noted.
Color-coated service handles and hole cutouts in countertop are provided. Fixtures are not factory installed. |
|
Deck Mounted Laboratory Plumbing |
|
|
Laboratory Electrical Services |
|
![Outlets Outlets](images/lab_furn images/Outlets1.jpg) |
Outlets Brushed cast aluminum box with stainless steel cover. Please specify desired location of pedestal box. |
![Electrical Chase Electrical Chase](images/lab_furn images/ElectricalStrip2.jpg) |
|
Single Gang |
Double Gang |
Single Face |
Double Face |
Single Face |
Double Face |
Duplex/115 V/15a |
50131S |
50131D |
50031S |
50031D |
Single/230 V/20a |
50132S |
50132D |
50032S |
50032D |
GFI Duplex/115 V/20a |
50135S |
50135D |
50033S |
50033D |
One Duplex and One Single/250 V/20a |
50034S |
50034D |
|
Electrical & Data Supply Chase
Anodized aluminum raceway can
be supplied with a variety of electrical
or data services.
• Specify length, type of plug, quantity
of plugs, type of data outlet.
Cat No. 50086 |
|
Laboratory Safety Equipment & Supplies |
|
Laboratory Safety Equipment to protect the laboratory users, and promote safety. HEMCO offers a wide range of laboratory safety
services, including eye /face washes, safety decontamination shower booths and safety stations. |
|
![Hand Held Face Wash Hand Held Face Wash](images/se images/FaceWash1.jpg) |
![Hand Held Face Wash Hand Held Body Wash](images/se images/FaceWash2.jpg) |
![Swing out Eye Wash Swing out Eye Wash](images/se images/FaceWash3.jpg) |
![Pull Down Eye Wash Pull Down Eye Wash](images/se images/FaceWash4.jpg) |
|
Hand Held Eye Wash
Deck mounted next to sink.
Includes 8’ hose and surface
escutcheon. 3/8” NPT. Barrier free. Cat. No. 93967 |
Hand Held Body Wash - squeeze valve nozzle on 8’ coiled hose and bracket. Can be used to rinse all body parts while victim is sitting or lying down. Wall or hood mounted, 3/8 NPT, barrier free. Cat No. 16005 |
Swing-Out Eye Wash
Deck mounted next to sink. Activates
when pivoted. 1/2” NPT. Barrier free. Cat. No. 16009 |
Pull-Down Eye Wash
Recessed, wall mounted
(4” deep), pull-down eye wash
safety station. Stainless steel.
1/2” NPT. Barrier free. Cat. No. 93968 |
|
|
Emergency Shower Decontamination Booth |
|
Emergency Shower Decontamination Booths, Strip curtains, Alarm horns, Alarm lights, Grab bars, Eye/Face Wash, Overhead Drench Shower, Hand Held Eye/Face Wash |
|
Durable one-piece seamless fiberglass construction with
glass smooth white surfaces and coved corners for ease
of clean-up. |
|
OSHA & ANSI state that emergency shower is to be located within 10 seconds walking time from the hazardous site location |
![Hand Held Face & Body Wash](images/lab_furn images/HandHeld FaceBody Wash.jpg) |
Hand Held Face & Body Wash
Mounted on the front side-wall of the
fume hood. Includes 8’ hose and
surface escutcheon. 3/8” NPT.
barrier free. Cat. No. 93966 |
|
|
Emergency showers available with translucent frosted strip curtains, which provides for easy access into booth, while containing contaminated water splash.
|
|
Stainless steel Grab bars located on right & left sides to support victim and rescue personnel during decontamination, included.
|
|
Plumbing is provided, for installation by local certified plumber. Plumbed to single point 1-1/4” IPT. connection. Tempered warm water supply connection 20 GPM water supply is required.
|
|
Raised fiberglass deck with self draining containment basin, and 2” diameter drain outlet located on either the bottom or rear of unit. |
|
Industrial Applications Emergency Drench Shower Booth,unit is equipped with pull rod activated overhead drench shower and rear wall mounted eye/face wash.
Cat No. 16601
|
|
Laboratory Applications Emergency Drench Shower Booth, same specs as above except with finished exterior side panels.
Cat No. 16604 |
|
|
Multi Purpose Safety Stations |
![BTT](images/back.gif) |
|
Constructed of 3/4" Polypro for durability, sanitation & corrosion resistance. Equipped with a pull rod activated shower and push handle eye / face wash for quick rinsing of eyes, face and body |
|
![](images/safety equipment images/Safety Station2023.jpg) |
1. Eye/Face Wash
2. Overhead Drench Shower
3. Safety Storage Cabinet |
• All in only 5 or 6 sq. ft. of Floor Space! |
• Constructed of 3/8” Polypro for durability, sanitation & corrosion resistance. |
• Shipped completely assembled, ready to install. |
• All plumbing is ready to connect. |
• Fixtures meet ANSI Z358.1 standard for Safety Showers. |
• Ideal for work sites where persons may be exposed to potentially
hazardous chemicals. |
•The HEMCO Safety Station is equipped with a pull rod activated shower
and push handle eye/face wash for quick rinsing of eyes, face and body. |
•Towels and first aid supplies can be stored in the cabinet below. |
• Safety Stations are fully assembled and ready for installation to water
supply & drain. |
• Supply 1.5” NPT, Drain 1.25” NPT. |
|
![Safety Stations Safety Stations](images/se images/SafetyStation3.jpg) |
Safety Station Specifications |
“A” Width |
A = 30” wide x 84” high x 24” deep.
Unit is equipped with Drench Shower, Eye/Face Wash &
Storage Cabinet
Cat. No. 78001 |
A = 36” wide x 84” high x 24” deep.
Unit is equipped with Drench Shower, Eye/Face Wash &
Storage Cabinet
Cat. No. 78002 |
|
|
|
|
|
|
